JVC DLA-NZ8 D-ILA projector

JVC DLA-NZ8 D-ILA projector

$ 40.53

$ 162.12

Unavailable
JVC DLA-NZ8 D-ILA projector

JVC DLA-NZ8 D-ILA projector

$ 40.53

$ 162.12

Unavailable
Please select combo product attributes
The combo subtotal is $,SAVE$

Product Details

JVC DLA-NZ8 D-ILA projector

The DLA-NZ8 D-ILA projector is the world's first home theatre projector to feature 8K/60p/4K120p input. It is equipped with a new 8K/e-shiftX proprietary technology to reproduce 8K-quality images. The projector is driven by three native 4K D-ILA devices, a high-quality 65 mm glass lens, and an Ultra-High Brightness of 2,500 lumens. The BLU-Escent laser diode light source also contributes to project images that come close to reality. Compatible with the latest HDR10 , the projector boasts industry-leading HDR performance. 8K, Laser, and HDR are the keywords that describe JVC's DLA-NZ8. *As a home theatre projector, as of September 2021, according to research by JVCKENWOOD.


    Frame Adapt HDR Generation 2


    The Frame Adapt HDR technology, which uses a proprietary algorithm to instantaneously analyze the maximum brightness of HDR10 content per frame and adjust the dynamic range in real time to the optimum range for video projection on projectors, has evolved into the second generation. As the culmination of the HDR image processing technology that we have cultivated up to now, we have completely reexamined the tone mapping algorithm in accordance with the scene and frame, and have achieved HDR images with higher definition and full of three-dimensional feeling by suppressing the whiteness especially in the high brightness area.

    Light source control by Gauge


    Laser light source adjustment function that can be finely adjusted according to the environment and preference. After the update from the previous 3 steps, fine adjustment of 0 -100 steps is possible, and adjustment based on the brightness on the screen and flexible setting according to the use environment are possible.

    USB Back-up

    USB backup function that can save and write all settings at once.

    This function saves the settings on the main unit menu to a commercially available USB flash drive. Professional adjustments can be saved or backed up in advance to undo unintended adjustments by children or family members.

    Features:

    • Newly developed 8K/e-shiftX technology reproduces 8K image quality
    • BLU-Escent Laser Light Source
    • High brightness of 2,500 lm provides vibrant and dynamic images
    • Native Contrast Ratio of 80,000:1 translates to a spectacular Dynamic Contrast Ratio of :1
    • 2x HDMI (48 Gbps, HDCP 2.3) inputs, supporting 8K60P and 4K120P input signals
    • HDR10 contains the metadata of the producers intentions for each scene, and with such data, the projector is able to automatically reproduce images as the creator intended.
    • Frame Adapt HDR dynamically tone maps any HDR10 content frame-by-frame or scene-by-scene and automatically performs adjustment to achieve optimal images close to reality as seen by human eyes. As a part the Frame Adapt HDR, the projector offers improved gamma processing accuracy from 12- to 18-bit equivalent to reproduce smoother and finer gradation. Additional Frame Adapt HDR picture modes allows for optimum playback with the widest variety of lighting conditions or theater environments. *
    • Theater Optimizer function, which works in Frame Adapt HDR mode, offers optimum HDR images by analyzing usage environments using the screen size and gain information and intelligently adjusts tone mapping. HDR Quantizer with New Auto (Wide) level mode provides brighter/more dynamic HDR images.*
    • Auto Tone Mapping function automatically adjusts settings for optimum HDR10 image quality.
    • New FILMMAKER MODE that faithfully recreates the creators intentions.

    Specifications:

    Device

    D-ILA Technology

    Yes

    Chip Type

    0.69-inch 4K D-ILA device

    Native Resolution

    4096 x 2160

    Number Of Chips

    3

    8K/e-shiftX

    Yes

    Display Resolution

    8192 x 4320

    Light Source

    Laser

    Yes

    Type

    BLU-Escent Laser Diode

    Life Time (Standard Mode)

    20000 hours


    Brightness

    2500 lm

    Dynamic Contrast

    : 1

    Native Contrast

    80000 : 1

    Dynamic Light Power control

    Yes

    Modes

    Mode 1 (gentle), Mode 2 (strong), Off

    Manual Aperture

    Yes

    Range

    -15 (stops down) to 0 (opens up)

    DCI-P3 Color Gamut

    Yes

    100% REC 709

    Yes

    Color Bit Depth

    12 bit

    HDR

    HDR10

    Yes

    HDR10

    Yes

    Frame Adapt HDR

    Yes

    Theater Optimizer

    Yes

    HLG

    Yes

    Auto Tone Mapping

    Yes

    Mastering Info Display

    Yes

    Mastering Info Display

    Yes

    Info data

    MaxCLL and MaxFALL mastering data
    HDR Picture ModesBT.709 / BT.2020 / DCI / HDR

    Lens

    Zoom

    2 x

    Throw Ratio

    1.43-2.92:1

    Diameter

    65 mm

    Material

    All-glass

    Build

    17-element, 15-group in full aluminium lens barrel.

    Lens Shift

    Yes

    Range Horizontal

    34 %

    Range Vertical

    80 %

    Motorized Zoom

    Yes

    Motorized Shift

    Yes

    Motorized Focus

    Yes

    Projection Display size (diagonal)

    60 - 200 inch

    Memory Function

    Yes

    Number of user presets

    10

    Lens Cover

    Yes

    HDMI

    HDMI

    Yes

    Number of Inputs

    2

    Data Rate

    48 Gbps

    HDCP Version

    2.3

    8K60P signal input

    Yes

    4K120p signal input

    Yes

    4K60P signal input

    Yes

    Video Signal range

    480p, 576p, 720p 60/50, 1080i 60/ 50, 1080p 120/ 100/ 60/ 50/ 30/ 25/ 24, 3840 x 2160p 120/ 100/ 60/ 50/ 30/ 25/ 24, 4096 x 2160p 120/ 100/ 60/ 50/ 30/ 25/ 24, 7680 x 4320p 60/ 50/ 30/25 /24

    PC Signal range

    VGA / SVGA / XGA / WXGA / WXGA / SXGA / WSXGA / UXGA / WUXGA / WQHD (60) / WQHD (120)

    Input Level Adjustment

    Auto / Standard (16-235) / Enhanced (0-255) / Super White (16-255)

    Color Space Range

    Auto/ YCbCr4444 / YCbCr422 / RGB
