KASA500 is a powerful Class-D Dual 250WPC amplifier
This DSP controlled system amplifier is optimized to deliver thunderous bass from KEF Ci subwoofers.With both line and speaker level inputs, and DSP configurable pass-through with optional high pass filters the KASA500 is versatile and can be deployed in limitless system configurations. Optional rack mount ears included.
To allow for future flexibility KEF engineers may update the KASA500 DSP firmware to optimize performance with additional KEF speakers. The KASA500 Programmer* is a proprietary tool for updating the KASA500 firmware. NOTE: KASA500 software requires a "USB Type A Male to USB Type A Male cable" for connection between your computer and the KASA500.
Hide Your Speakers, Not Your Sound
KEF approaches the development of architectural loudspeakers with the same diligence as any other model; our passion for acoustic excellence wouldnt allow anything else. The combination of innovative engineering and sophisticated acoustic design ensures KEFs architectural speakers offer as compelling a performance as its stand-alone hi-fi speakers.Specifications:
| Model | KASA500 |
| Amplifier Power (<1% THD) | 2 x 250watts 4ohms; Bridge 1 x 500watts 8ohms |
| Crossover Frequency | 40-140Hz or software bypass |
| Inputs | Selectable stereo RCA line level, or mono LFE RCA level; Stereo speaker level |
| 12-Volt trigger input voltage | 8 to 14 Volt [email protected] max "diameter female plug (tip positive or tip negative) |
| External Dimensions | 88 x 432 x 304mm (3 x 17 x 12 in.) |
| External Dimensions (H x W x D) (with feet) | 92 x 432 x 304mm (3 x 17 x 12 in.) |
| External Dimensions (H x W x D) (with rack ears; 2 EIA rack space) | 88 x 483 x 304mm (3 x 19 x 12 in.) |
| Weight | 4kg (9 lbs) |
| Finish | Black |
