Features:
- Front-firing port for low bass extension
- Dual 6.5-inch Cerametallic woofers
- 6- by 10-inch Tractrix Horn Tweeter with 1-inch titanium-dome compression driver
- Top-of-the-line internal wiring
Specifications
- Frequency Response: 48Hz - 20kHz 3dB
- Sensitivity: 97dB @ 2.83 volts / 1 meter
- Nominal Impedance: 8 ohms compatible
- High Frequency Crossover: 1400Hz
- Power Handling: 150 watts maximum continuous (600 watts peak)
- Enclosure Type: Bass reflex via front-mounted port
- Enclosure Material: Medium Density Fiberboard (MDF) construction
- Tweeter: 1" (2.5cm) magnetically shielded titanium dome compression driver with a 9.6oz ceramic magnet structure
- High Frequency Horn: 10" x 6" rectangular 90x 60 Tractrix Horn
- Woofer: Two 6.5" (16.5cm) magnetically shielded Cerametallic cone drivers with cast aluminum frame
- Inputs: Two sets of binding post speaker terminals (connected via brass strap jumpers)
- Dimensions: 15" (38.1cm) H x 17" (43.2cm) W x 12.5" (31.8cm) D (with grille)
- Weight: 39 lbs. (17.7kg)
- Finish: Galaxy Black cabinet with Black anodized aluminum fascia
- Mounting: 4-bolt pattern, 1/4"-20 thread
