Ideal for hallways, or any area where space does not allow for stereo pairs.

Optional square or premium grille can be used with this model.

Frequency Response
60 Hz 25 kHz

Nominal Impedance
6 6 ohms

Sensitivity (1W@1M)
88.5 dB

Maximum SPL
107.9 dBA

Power Handling (RMS)
65 W

Recommended Amplifier Requirements
20 65 W

Drive Unit Complement
6 1/2" MMP II cone bass driver
2 x 1" C-CAM pivoting Gold Dome tweeters

Overall Diameter (Including Grille)
250 mm (913/16")

Overall Depth (Including Grille)
120 mm (43/4")

Mounting Depth
116 mm (49/16")

Cut-Out Hole Diameter
211 mm (81/4")

Optional Square Grille - Outer Dimensions
249 x 249 mm (9 3/16")

Fixing Type
3 position Tri-Grip dog fixings

Construction Material
Mineral filled ABS, RoHS compliant

Weight
2.08 kg (4 lb 10 oz)

Pre-Construction Bracket
CB6 Pre-Construction Bracket (Purple)

Back Box
CCBOX-R | CMBOX-R

Sold As
Single Unit
