Specifications

• • Power Output:

    • 45 watts per channel into 8 ohms (stereo mode)

    • 150 watts into 4 ohms (bridged mono mode)

  • Peak Current Capability: 60 amps instantaneous peak current Inputs: Balanced XLR only

  • Output Stage: 16 discrete power transistors, each mounted on individual finned heatsinks

  • Power Supply: Dual-mono architecture with separate bridged rectifiers and reservoir capacitors for each channel; shared mains transformer with separate secondary windings

  • Design:

    • Fully balanced signal path with operational amplifiers for input processing and discrete transistors in gain and pre-driver stages

    • Bridging capability for mono operation, delivering increased power output

  • Dimensions: Approximately 440 mm (W) x 45 mm (H) x 165 mm (D)

  • Weight: Approximately 5 kg
