ONKYO combines the best of both worlds with the brand new TX model 8470. An
exquisite audio performance instrument, inherited from more than 75 years of a
tireless commitment to design excellence and sound precision, combined with the
last up-to-date features in terms of connectivity and video abilities.

FEATURES
Powerful Output: 140 watts per channel 4 ohms @ 1%THD
Vinyl-Friendly Design: Isolated selectable MM/MC phono board for clear
audio performance
Streaming Ready: Integrated with Roon Ready, Tidal, Deezer and Spotify
High-Quality Components: Gold-plated terminals, audio-grade capacitors,
and copper additional pads for optimal sound
Advanced DAC and Amplifier: AKM Premium 32-bit / 768 kHz Stereo
2-Channel DAC and G Class amplifier
TV Integration: HDMI ARC (4 in / 1 out) and 8K visual content processing,
Other inputs: 2 Optical,1 Coaxial, 3 Analog Stereo inputs
FM/DAB Tuner: Enjoy your favorite radio stations with ease

SPECIFICATION
Power and Amplication

- 2 x 120 Watts / 8 ohms / 1 % THD / 2ch driven
- 2 x 140 Watts / 4 ohms / 1 % THD / 2ch driven
- Class G Amplifier

HDMI and Video Inputs

- 4 In / 1 Out (ARC)
- 8K/4K Ultra HD

Audio In/Out

- 4 HDMI, 3 RCA, 2 Opt, 1 Coax, 1 MM/MC selectable
- 2 USB inputs
- 1 Zone 2 Preout
- 1 Subwoofer out

Power supply

- AC 220-240V ~ 50/ 60 Hz

Dimensions - (W x H x D) 435 x 149 x 329 mm
Weight - 19.8 kg
Warranty - 2 Year Warranty
