Onkyo TX-NR7100 9.2-Channel AV Receiver
Discrete Zone 3 HDMI Switching Set up different high-definition entertainment options with up to 8K60 resolution* in two different rooms from your Onkyo receiver when the kids dont feel like partaking in whatever you like or vice versa.** | |
KLIPSCH OPTIMIZE MODE
| |
ULTIMATE 4K GAMING
|
Take the room out of the equation
State-of-the-art Dirac Live Room Correction technology unlocks your loudspeakers' full potential, improving audio performance across the full frequency band without additional upgrades. Dirac Live automatically calibrates sound in your room using either your smartphone and the included wired mic or virtually wireless with the Dirac Live PC or MacOS* application and a 3rd party USB mic (not included). Now, you'll get a more accurate measurement of your surround sound system's positioning to be more precise and balanced, providing a better result with the increased upper limit of delay time from 20 to 50 milliseconds.
*Device must be connected to the internet and the same network as your AVR
Specifications:
| Power output (All channels) | 220 W/Ch (6 ohms, 1 kHz, 10% THD,1-ch driven) 100 W/Ch (8 ohms, 20 Hz20 kHz, 0.08% THD, 2-ch driven, FTC) |
| Dynamic power | 250 W (3 ohms, Front) 220 W (4 ohms, Front) 130 W (8 ohms, Front) |
| THD N (Total Harmonic Distortion Noise) | 0.08% (20 Hz20 kHz, half power) |
| Input sensitivity and impedance | 0.08% (20 Hz20 kHz, half power) |
| Input sensitivity and impedance | 200 mV rms/47 k-ohms (Line) 3.5 mV rms/47 k-ohms (Phono MM) |
| Rated RCA output level and impedance | 1 V rms/470 ohms (Subwoofer pre-out) 200 mV rms/470 ohms (Zone 2/Zone B line-out) |
| Frequency response | 10 Hz100 kHz/ 1 dB, -3 dB (Direct/Pure Audio) |
| Tone control | 10 dB, 20 Hz (Bass) 10 dB, 20 kHz (Treble) |
| Signal-to-noise ratio | 106 dB (Line, IHF-A) 80 dB (Phono, IHF-A) |
| Speaker impedance | 416 ohms |
