We at Paradigm are thrilled to present you with the latest addition to our range of affordable and performance-oriented Custom Installation products. The Paradigm DCS-208 is an all-new design, improving and expanding on the innovations youve come to expect from us in the world of performance audio. The Paradigm DCS-208, the perfect blend of performance and practicality. With powerful bass and zero-footprint, you get the best of both worlds, allowing you to add bass to any room without taking up valuable floor space.
Easy to Install, Anywhere
A Fire Rated integrated enclosure makes the DCS-208 suitable for residential and commercial applications. Designed for fast installation into existing rooms without the need for expensive and time-consuming drywall repairs. Simple installation, no footprint, Paradigm performance.
Proven Paradigm Performance
Purpose-built for high output from a compact enclosure, with high-efficiency and low distortion. The dual, 8 High-Excursion Carbon-Fiber-Reinforced Polypropylene woofers have a larger surface area than a 10 sub for powerful, accurate bass. The integrated enclosure ensures consistent performance in any application while reducing sound transmission to other areas of the home.
Distributed Audio Meets Its Match
Anthems MDX series amplifiers have made adding bass to whole home music systems easier than ever. For these distributed audio systems, the DCS-208FR3 can easily be driven off the bridged subwoofer output allowing you to take advantage of the MDXs robust bass management, custom DSP profiles, and advanced ARC Genesis room correction for optimized performance in any environment.
Performance and Practicality All-In-One
Other Features:
Ultra Rigid Stamped Steel chassisand baffles and die-cast aluminum clamps add strength and rigidity for better bass performance, along with a more durable installation.
Magnetically attached grilles:neodymium magnets hold grilles firmly in place.
Integrated Fire-Rated Back-box Enclosure for an Easy and Reliable Installsafeguards internal parts from debris while preventing added sound spillage to adjacent rooms. The integrated backer box enclosure also ensures consistent and reliable performance from application to application.
Nickel-plated, spring-loaded binding postsfeature a larger wire hole to accept higher-gauge wire or banana plugs.
Premium-grade components include high-power rated resistors, capacitors and heavy gauge wire inductors.
In-Room or In-Wall, How about both?
The DCS-208 is the first in-wall model in the highly acclaimed Defiance series. The first Defiance in-wall brings the performance of Defiance subs to more rooms than ever before. With a minimalist look, the Paradigm DCS-208 is the perfect way to bring home proven Paradigm bass performance without compromise. Bass theyll remember, with a look theyll forget.
Specifications
- Design: Dual 8" high-excursion drivers, in-wall
- Chassis/Mounting Bracket: GRIP chassis/mounting bracket with custom steel enclosure
- Amplification: Amplifier required (sold separately)
- Low Frequency Driver:
- Two 210-mm (8 in) CFP carbon-fiber-reinforced polypropylene cones
- 38-mm (1-1/2 in) voice coils
- Over-molded TPR surrounds
- 38-mm (1-1/2 in) 8-layer copper wire voice coils
- High-temperature polyamide formers
- Ceramic/ferrite magnet structures
- Low Frequency Extension: 35 Hz (DIN)*
- Suitable Amplifier Power Range: 50-600 W
- Maximum Input Power: 300 W
- Finishes: White, paintable
- Overall Dimensions: 19-1/8 x 10-3/4 x 4.5 (48.5cm x 27.2cm x 11.5cm)
- Cut-Out Dimensions: 18x 9-5/8 (45.7cm x 24.5cm)
- Minimum Mounting Depth: 3-7/8 (9.8cm)
- Recommended Amplifiers: MDX-8, MDX-16, X-300
- Internal Volume: 7.5L
- Frequency Response: /-3 dB from 77 Hz to 190 Hz
- Weight: 26.7 lbs (12.5 kg)
