PRODUCT SPECIFICATIONS
- Power: 120 Watts RMS per channel into 8 Ohms. Both channels driven from 20Hz to 20kHz at less than 0.1% total harmonic distortion
- Frequency Response: 20Hz to 20kHz 0.2dB. 0dB at 0Hz and -3dB at 70kHz
- Distortion: Typically <0.05% THD at rated power. 0.1% THD & IM worst case prior to clipping
- Current Output: 20A short duration peak per channel. Fuse protected
- Slewing: 50V/us
- Hum & Noise: 90dB below rated output 20Hz to 20kHz unweighted
- Input Sensitivity: 290mV RMS for rated output at 1kHz
- Input Impedance: 47k Ohms
- Input Overload: 5V RMS
- Rated Pre Out Level: 1.5V RMS into 47k Ohms or higher
- Pre Out Source Impedance: Typically 1.5k Ohms
- Pre Out Minimum Recommended Load: 47k Ohms
- Tape Output Level: Unity Gain at 200mV. Tape loop muting at 5V RMS input
- Dimensions: Height 105mm (4"), Width 450mm (17.75"), Depth 400mm (15.75"), Weight 10kg (22lb)
