EMOTION
Understanding music is to understand the emotion upon which music is created the passion and story behind the music that drives artists to create. With unmatched experience in every facet of music creation, embedded deep in the Yamaha DNA is an intimate understanding of the emotional essence of music and music creation. Conveying the artists emotion through our Hi-Fi equipment is a fundamental component of the Yamaha design philosophy.
Toroidal Transformer
Usually reserved for flagship Hi-Fi components, the A-S1200 benefits from the technical proficiency and absolute musicality of a toroidal transformer. Combined with an array of high-end Hi-Fi features and components, the toroidal transformer assists in ensuring the musical emotion is conveyed to the listener.
Gorgeous Level Meters
The level meters are both a nod to the nostalgic era of Hi-Fi, while simultaneously demonstrating the return of pure Hi-Fi for todays discerning enthusiast. Visually presenting the dynamics and pulse of the music, the level meters imbue a warm feeling through their softly illuminated LEDs.
An open sound stage presents the listener with a musical experience that is similar to being at the live performance. True Hi-Fi delivers this openness in the sound, transforming the listeners musical experience, bringing them closer to the artist.
Rated Output Power [20 Hz-20 kHz, 0.07% THD] 90 W 90 W (8 ohms), 150 W 150 W (4 ohms)
High Dynamic Power/Channel (8/6/4/2 ohms) 105/135/190/220 W
Damping Factor 250 (1 kHz, 8 ohms)
Frequency Response 0 / -3 dB (5Hz-100kHz) , 0 / -0.3 dB (20 Hz-20 kHz)
RIAA Equalization Deviation /-0.5 dB (PHONO (MM/MC))
Total Harmonic Distortion (20Hz to 20kHz) PHONO MCLINE2 OUT: 0.02% (1.2 Vrms), PHONOLINE2 OUT: 0.005% (1.2 Vrms), CD, etc.SP OUT: 0.035% (50 W/8 ohms
Signal-to-Noise Ratio PHONO MC: 90 db, PHONO MM: 96 dB, CD, etc.: 110 dB
Input Sensitivity [1 kHz, 100 W/8 ohms] PHONO MC: 150 uVrms/50 ohms, PHONO MM: 3.5 mVrms/47 kohms, CD, etc.: 200 mVrms/47 kohms, MAIN IN: 1 Vrms/47 kohms
Transformer 625VA (Toroidal)
Dimensions (W x H x D) 17-1/8" x 6-1/8" x 18-1/4"
Weight 48.5 lbs
