Whether its mounted with the unique isolation options included or even used as a floorstander, with professional installation as part of a Cinergy system, youll have world-class cinema sound in your own home. Far superior to your local mainstream cinema, which is normally designed for larger groups to deliver the best median performance for everybody. Cinergy, on the other hand, is a cinema built around you and those closest to you.

THX Certification
THX Certified Ultra

System Format
3 Way

Sensitivity (2.83 Vrms @ 1 M)
90 dB

Maximum Linear SPL**** (@1m, free space)
Continuous 109 dB, Peak 122 dB

Power Handling (RMS)
Continuous 350 W, Peak* 1400 W

Nominal Impedance
4 Ohms

Minimum Impedance (20 Hz - 20 kHz)
3.8 Ohms

Recommended Low Frequency Crossover Frequency
40 - 80 Hz (High Pass)

Recommended Amp Requirements (RMS)
200 - 1400 W (IA750-2 or IA750-4)

Bass Alignment
Ported**

Port Tuning Frequency
38 Hz**

LF Extension, In Wall, With Port Bungs (- 6dB)
42 Hz

LF Extension, In Free Space, No Port Bungs (- 6dB)
42 Hz

HF Extension (-6dB)
>30 kHz

Drive Unit Complement
2 x 8" RDT Driver
2 x 2.5" C-CAM Driver
1 x MPD Transducer

External Dimensions (Cabinet Only (H x W x D))
1080 x 300 x 240 mm (421/2 x 1113/16 x 97/16")

External Dimensions (Inc Grille) (H x W x D)
1080 x 300 x 253.6 mm (421/2 x 1113/16 x 10")

Max External Dimensions (Inc all Fittings) (H x W x D)
1132 x 438 x 253.6 mm (449/16 x 171/4 x 10")

Weight
40.4 kg (88 lb 14 oz)

Conditions
* Calculated from a peak voltage, this is not a true power figure but useful for comparisons.

** When used in an In-Wall or On-Wall configuration it is recommended to use the fitted port bungs to control bass output. This will effectively make the product a sealed box.

*** Band limited with Low pass at 200 Hz, should only be used with IA800-2C and the correct speaker profile.

**** Tested with a music like noise signal with distortion and power compression remaining below audible limits.

THX
THX Certified Loudspeakers.
