Technology
- 4" bass driver - Radius features all new bass drivers with concave cone profiles, introduced by our top-of-the-range Platinum speakers and applied subsequently to Gold GX. Extensive research and FEA modelling have allowed us to perfect the relationship between the new radiating diaphragm and its motor design, introducing larger motor sizes and voice coils for increased excursion, higher power capability and reduced distortion.
- C-CAM Gold Dome tweeter - optimised to deliver the finest and widest performance within the compact Radius cabinets. It benefits from a more efficient rear-venting design, releasing air trapped and compressed at the back of the tweeter dome, and guiding it around the drive assembly to a rear-loading chamber.
- Single through-bolt driver fixing provides mechanical de-coupling and enhanced mid-band clarity and resolution. The through-bolts also act as rigid cross bracing to give a very solid non-resonant cabinet.
- Wall mounting bracket Included
SPECIFICATIONS
Frequency Response
90 Hz 35 kHz
Sensitivity (1W@1M)
87 dB
Nominal Impedance
6 ohms
Power Handling (RMS)
75 W
System Power Handling (RMS)
100 W
Recommended Amplifier Requirements
30 100 W
Maximum SPL
106 dBa
Bass Alignment
C:Bass reflex - Front ported L/R:Bass reflex - Side ported
Drive Unit Complement
3 x 4" (100 mm) cone bass/mid driver
3 x 1" (25 mm) C-CAM Gold Dome tweeter
Cabinet Dimensions (H x W x D)
175 x 980 x 67 mm (67/8 x 389/16 x 25/8")
Cabinet Dimensions (Including Grille and Terminals (H x W x D))
175 x 980 x 79 mm (67/8 x 389/16 x 31/8")
Cabinet Dimensions (Including Grille and Bracket (H x W x D))
175 x 980 x 84 mm (67/8 x 389/16 x 35/16")
Pre-Construction Bracket
Dedicated bracket included
Weight
7.4 kg (16 lb 4 oz)
Sold As
Single Unit
