Specifications

• Design:

  • Single speaker system with stereo L/R inputs, 3-driver, 2 x 2-way acoustic suspension, weather, water, UV-resistant PolyGlass enclosure

• Crossover:

  • Two 3rd-order electro-acoustic at 2.3 kHz

• High Frequency Driver:

  • Two 25-mm (1 in) PTD domes

• Frequency Response On-Axis:

  • 2 dB from 75 Hz - 20 kHz

• Frequency Response 30 Off-Axis:

  • 2 dB from 75 Hz - 15 kHz

• Mid/Bass Frequency Driver:

  • Dual voice-coil, 190-mm (7-1/2 in) ICP cone, die-cast chassis

• Sensitivity Room / Anechoic:

  • 93 dB /

• Low Frequency Extension:

  • 50 Hz (DIN)

• Suitable Amplifier Power Range:

  • 15 - 110 watts Mono; 15 - 55 watts / channel Stereo Input

• Maximum Input Power:

  • 80 watts Mono; 40 watts / channel Stereo Input

• Impedance:

  • Compatible with 4 ohms Mono; 8 ohms / channel Stereo Input

• Finishes:

  • Black, White

• Dimensions (HxWxD):

  • 12.625" 8.875" 8.75" (32.1cm 22.5cm 22.2cm)

• Weight:

  • 10.6 lbs. (4.8 kg)
